Item No. :
HTB20Lifting height :
3000MM (OPTIONAL)Lifting Capacity :
2000KGSOEM/ODM :
SUPPORT
HTB20 Electric Forklift With Lithium Battery
|
|||||||
Power |
|
LI-ION |
|
Minimum turning radius |
mm |
2100 |
|
Rated lifting capacity |
KG |
2000 |
Minimum right angle channel width |
mm |
3670 |
||
Load centre distance |
mm |
500 |
Gantry inclination angle |
(°)m |
5/10 |
||
Operation mode |
|
Driving |
Maximum lifting speed without load |
m/s |
325 |
||
Overall length |
with fork |
mm |
3395 |
Maximum lifting speed under full load |
250 |
||
without fork |
mm |
2310 |
Maximum operating speed without load |
Km/h |
15 |
||
Width |
mm |
1100 |
Maximum operating speed under full load |
14 |
|||
Height |
Height of no-lifting |
mm |
2035 |
Maximum climbing slope under full load |
% |
15 |
|
Height of roof gard |
mm |
2020 |
Forklift weight |
Kg |
2780 |
||
Maxium height during operation |
mm |
4110 |
Tyre (optional) |
|
Pneumatic OR solid tyre |
||
Wheelbase |
mm |
1520 |
|
|
|
||
Front overhang |
mm |
370 |
Front tyre size |
|
6.5-1 |
||
Rear overhang |
mm |
380 |
Rear tyre size |
|
5.00-8 |
||
Front track width |
mm |
904 |
Brakes |
|
Foot brake |
||
Rear track width |
mm |
958 |
Park brakes |
|
Hand brake |
||
Minium ground clearance |
mm |
110 |
Battery voltage/capaci |
V/AH |
80V/105AH |
||
Standard lifting height |
mm |
3000 |
Charger |
V/A |
80V/35A |
||
Free lifting height |
mm |
0 |
Drive motor power |
Kw |
13 |
||
Fork adiustment range |
mm |
260-1100 |
Oi1 pump motor power |
|
13 |
