l Perkins power features low energy consumption and environmental protection.
l The closed hydrostatic system has the feature of lower energy consumption.
l Simple quick-change construction can meet multipurpose operation of users.
l The integrated multi-functional control handle makes operation simple.
l The monitor has the LED showing of fuel level by stages.
l The unique frame hinge type is compacted and durable.
l The widely applied broad-face tyre and damping seat is safe and comfortable.
l Small working radius, mobile and flexible.
Item No. :
HT908MLoad Capacity :
800KGSOperating Weight :
2800KGSBucket Capacity :
0.6m³OEM/ODM :
SUPPORT|
Engine |
|
|
Model |
403J-11 |
|
Rated power |
18.5kw(24.8BHP) |
|
Rated speed |
2800rpm |
|
Maximum torque |
67Nm |
|
The ratio of fuel consumption |
252g/kwhr |
|
Dimensions |
|
|
Body length |
3775mm |
|
Body width(reverse tyre) |
1325mm |
|
Body height |
2350mm |
|
Minimum ground clearance |
260mm |
|
Maximum dumping height |
2000mm |
|
Dumping reach |
600mm |
|
Wheel base |
1575mm |
|
Performance parameters of the machine |
|
|
Bucket |
0.4m3 |
|
Tipping load in shovel, vehicle straight raight straight 798kg |
980kg |
|
Tipping load in shovel, vehicle at 68° |
600kg |
|
Operating weight |
kg |
|
The sum of the work device |
8s |
|
Driving speed |
0-17km/h |
|
Minimum turning-circle radius |
|
|
Outside face of bucket |
mm |
|
Outside face of tyre |
mm |
|
Tyre specifications |
31*15..5-15TL |
|
Maximum turning angle |
±50° |
