1100kg Wheel Skid Steer Loader with high quality is a versatile construction machinery primarily used for digging, loading, and transporting loose materials. It is suitable for various locations, including urban infrastructure, roads or construction sites, factory workshops, warehouses, docks, ship decks, and even ship cabins.
Item No. :
HT100Load Capacity :
1100KGSOperating Weight :
3550KGSBucket Capacity :
0.55CBM1100KG Wheel Skid Steer Loader Parameters
| Model | LT100 |
|---|---|
| Operating load (kg) | 1100 |
| Max Speed（km/h） | 12\18 |
| Rated flux (L/min) | 75 |
| High Flow Flux (L/min) | 140 |
| Tire（track） model | 12-16.5 |
| Rated power (Kw) | 74 |
| Fuel tank capacity (L) | 90 |
| dead weight (kg) | 4000 |
| self weight bucket (kg) | 3550 |
| Bucket capacity (m³) | 0.55 |
| Overall operating height (mm) | 4070 |
| Height to top of cab (mm) | 2160 |
| Without bucket length(mm) | 2880 |
| Overall length with bucket(mm) | 3580 |
| Dumping height(mm) | 2450 |
| Width (mm) | 1880 |
| Bucket width (mm) | 1880 |
| Height to bottom of level bucket(mm) | 2983 |
| Dumping angle at maximum height(° ) | 40 |
| Height to bucket hinge pin (mm) | 3150 |
| Dumping reach(mm) | 700 |
| Rollback o bucket on ground(° ) | 30 |
| Rollback of bucket at full height(° ) | 104 |
| Wheelbase(mm) | 1185 |
| Ground clearance(mm) | 205 |
| Angle of departure(°) | 20 |
| Front turning radius without bucket(mm) | 1278 |
| Front tuning radius(mm) | 2144 |
| Rear tuning radius(mm) | 1857 |
| Rear axle to bumper (mm) | 1082 |
| Tread width (mm) | 1500 |
